产品应用
JYS系列小型化光纤连接器接纳Φ1.25mm标准陶瓷插芯、卡扣式锁紧连接、小型化金属外壳、能同时连接两芯或者四芯光纤。产品主要用于替换FC、LC等民用运动连接器。
产品特点
● 三键定位,有盲插和防错插功效
● 快速卡口连接
● 外壳体可选用差别质料及镀层适
● 接纳陶瓷插针和陶瓷套管对中定位,PC研磨
主要技术指标
● 插入损耗:≤0.5dB
● 事情温度:-55℃~+85℃
● 振动:10-2000Hz,功率谱密度 0.2?2/Hz
● 攻击:2940 ?/?2
● 机械寿命:500 次
注:须要时,可凭据客户特殊要求进行定制开发。
产品应用
● 航空
● 电子
● 武器
● 舰船
● 其它
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
